| Place of Origin: | Shanghai, China |
|---|---|
| Brand Name: | Lumsail |
| Certification: | CE |
| Model Number: | BS-BCA2C |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiated |
| Packaging Details: | Standard export packing |
| Delivery Time: | Within 3 working days after we received the payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 500 unit per month |
| Analysis Resource: | Multi-frequency Bioelectrical Impedance Analysis (MFBIA) | Electrode: | 8-Point Tactile Electrode System |
|---|---|---|---|
| Calculation Method: | No Empirical Estimation | Segmented Item: | Right Arm, Left Arm, Body, Right Leg, Left Leg |
| Control Panel: | Colorful Touch Screen | Interface: | USB2.0, RJ45 |
| Power Specification: | AC220V/50Hz Or AC110V/60Hz | Weight: | 22Kg |
| New Features 1: | Segmented Analysis On Arms/legs | New Features 2: | Wireless Connection To Computer |
| High Light: | RJ45 Interface Body Composition Analyzer,Wireless Biochemical Body Composition Analyzer,BMI Body Composition Analyzer |
||
Biochemical Analysis System Body Health Composition Scanner Analyzer
Body Composition Analyzer is designed to calculate regional body composition, empowering healthcare
professionals to better determine health risk associated with visceral and abdominal fat. The BS-BCA2 model
is based on the latest statistics method DXA, which analyzes human body composition including fat, weight,
BMI (Body Mass Index), none-fat and other health indicators through multi-frequency bio-electrical impedance
analysis method, also called MFBIA. It calculates by the built-in high performance computer, and gives
out instruction upon the analysis result for testers’ reference as plans to lose weight.
Current has different penetration force depending on frequency. Since low frequency cannot penetrate
cells and flow on the external surface’s water, it measures only water content outside cells, while higher
frequency means that you can measure even the water content inside cells since it penetrates inside cells,
that is, by using diverse frequency, the BS-BCA2 model can accurately measure water contents inside and
outside cells separately. When a body touches an electrode, contact resistance occurs, and it is important
to control the contact resistance in order to correctly measure the resistance in a body.
Applications of Biochemical Analysis System Body Health Composition Scanner Analyzer:
Features of Biochemical Analysis System Body Health Composition Scanner Analyzer:
New Features for Biochemical Analysis System Body Health Composition Scanner Analyzer
|
Product name
|
Body element fat analyzer
|
|
Product Model
|
BS-BCA2C
|
|
Test Method
|
Multi-frequency bioelectrical impedance analysis (BIA)
|
|
Test Frequency
|
Three different frequency(20HZ, 50KHZ, 100KHZ)
|
|
Electrode Method
|
8 point contact electrode
|
|
Rated current
|
less than 180μA
|
|
Power
|
Input power: AC100~240V, 50/60HZ
|
|
Screen
|
320*240 STN LCD Touching Screen
|
|
Operation Language
|
English and Multbeautye Language Option for body fat analyzer
body composition analyzer |
|
Values Storage
|
50000×10 and SD Card unlimited expansion is available
|
|
External Storage
|
SD Card transfer to computer for large storage
|
|
External Interfaces
|
RJ-45, USB2
|
|
Printer Interfaces
|
USB
|
|
IC Card System
|
standard IC card control
|
|
Test time
|
No more than 2 minutes
|
|
Operation Environment
|
Temperature: 10~40°C(50~1040°F),humidity: 30~80%RH, 500~600 hPa
|
|
Test scope of weight
|
10~200Kg; Test scope of age: 10~99 ages; Test scope of height: 90~200cm
|
|
Packing size
|
117*47*34.5cm
|
|
Gross weight
|
55kg
|
