Extracorporeal ESWT Shockwave Therapy Machine For Physiotherapy

Extracorporeal ESWT Shockwave Therapy Machine For Physiotherapy

  • High Light

    Extracorporeal ESWT Shockwave Therapy Machine

    ,

    Physiotherapy ESWT Shockwave Therapy Machine

    ,

    Dual Channel Shockwave Therapy Machine

  • Product Name
    Frozen Shoulder (Adhesive Capsulitis) AWT Acoustic Wave Therapy Machine
  • Miniwave Version
    Miniwave, Miniwave Pro, Miniwave Max
  • Miniwave Shockwave Applicator Weight
    0.6Kg
  • Energy
    Pro Version: 10 – 190mJ, Stepping 10mJ
  • Frequency
    Pro Version: 1 – 21Hz, Stepping 1 Hz
  • Pulse Mode
    Continuous
  • Output Channel
    Dual-channel Output, Max 2 Applicators Connected
  • Transmitter For Miniwave Pro
    6 Fully Alloy Made Transmitters 6mm / 15mm B /15mm U / 15mm F / 25mm / 36mm
  • Miniwave Applicator Lifespan
    2 Million Shots Or More
  • Miniwave Transmitter Lifespan
    300K Shots Or More
  • Control Panel On Main Unit
    Finger-swing Touch Control With OLED Screen
  • Control Panel On Applicator
    5-buttons Panel With OLED Screen
  • Pre-set Protocols
    Over 90 Preset Protocols On Miniwave APP For MINIWAVE PRO
  • Packing
    Aluminum Hand Case With Shaped Foam
  • Bluetooth
    Yes, Available On Pro Or Max Version
  • Application On Mobile Device
    Yes, Available On Pro Version
  • Place of Origin
    Shanghai, China
  • Brand Name
    Miniwave
  • Certification
    CE, FDA REGISTED
  • Model Number
    BS-SWT2X-S
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiated
  • Packaging Details
    Aluminum hand case with shaped foam for ESWT Shockwave Therapy Machine
  • Delivery Time
    Within 3 working days after we received payment of Miniwave ESWT Shockwave Therapy Machine
  • Payment Terms
    T/T, Western Union, MoneyGram, Cash, Alipay
  • Supply Ability
    100 units/month

Extracorporeal ESWT Shockwave Therapy Machine For Physiotherapy

ESWT Physiotherapy Extracorporeal Shockwave Therapy Beauty Machine



What is Jumper's knee (Patellar tendonitis)?
An injury to the tissue connecting the kneecap to the shin bone (patellar tendon).
The patellar tendon helps the muscles extend the knee. This injury is most common in athletes who frequently jump, such as when playing basketball and volleyball.
Knee pain, swelling, and stiffness are common symptoms.
Treatment usually begins with physical therapy and pain relief.
Jumper’s knee is caused by overuse of your knee joint, such as frequent jumping on hard surfaces.
It’s usually a sports-related injury, linked to leg muscle contraction and the force of hitting the ground. This strains your tendon. With repeated stress, your tendon may become inflamed.

What is Miniwave Shockwave Therapy?
Miniwave Shockwave Therapy is a method of therapy that uses a device to send acoustic waves of high energy pulses into an injury affected area on a person's body. The device works by creating a microtrauma to the affected area, thus stimulating blood flow and thereby promoting tissue healing. In chronic pain, these Shockwaves create a new inflammatory process, which then kick starts the brain to react by sending the necessary nutrients to promote healing.





Benefits of Miniwave Shockwave Therapy include:

  1. Fast pain relief
  2. Mobility restoration
  3. Accelerated tissue repair and cell growth
  4. Non-surgical
  5. Non-invasive

Specifications for Miniwave Shockwave Therapy Machine

MINIWAVE Parameter Basic Version Pro Version
Energy 10-150mJ, totally 9 levels 10-190mJ, stepping 5mJ
Frequency 1-14Hz, totally 9 levels 1-21Hz, stepping 1 Hz
Pre-set protocols 5 pre-set protocols, programmable More than 40 pre-set protocols, customizable
Bluetooth None YES
APP on mobile device None YES, Available for Android & IOS
History records management None YES
Operator management None YES
Rental management None YES
Main unit dimension 200 (width) x 230 (length) x 78 (height) mm
Main unit weight 1.27Kg
Applicator dimension 210 (length) x 50 (diameter) mm
Applicator weight 0.6Kg
Pulse Mode Continuous
Output channel Dual-channel output, max 2 applicators can connect together
Transmitter 6 fully alloy made transmitters 6mm / 15mm B /15mm U / 15mm F / 25mm / 36mm
Applicator lifespan 2 million shots or more
Transmitter lifespan 300K shots or more
Control panel on main unit Finger-swing touch control with OLED screen
Control panel on applicator 5-buttons panel with OLED screen
Foot pedal 360 degree foot pedal as optional accessory
Firmware upgradable Yes, via SD card
Power AC mode: Max.250W, AC110V-240V, 50/60Hz
Cordless DC mode: External Lithium-ion battery
*Battery is optional accessory, not included by default
Fuse F5 AC250V, 3A
Packing Aluminum hand case with shaped foam, with carton outside


FAQ for Miniwave Shockwave Therapy
Is there a situation or condition where Shockwave Therapy cannot be used?
Shockwave Therapy is not advised:

  1. Over or near bone growth centre, or until bone growth is complete
  2. When a malignant disease is in or near the treatment area
  3. Infection in the area is to be treated
  4. Over ischemic tissue in individuals with vascular disease
  5. For patients who have coagulation disorder or are taking anticoagulant medications
  6. For patients who have a prosthetic device in the area to be treated
  7. If the patient has a fetus in the treatment area.


How many sessions of Miniwave Shockwave Therapy do I need?
Effects start to occur after just 1 session. Most patients will notice a significant improvement in their pain symptoms & recovery within 3-4 sessions & a full treatment course is approximately 12 sessions. Your Physiotherapist will likely combine this with other modalities of treatment to give you the best outcome.

What does Miniwave Shockwave Therapy feel like?
People may experience mild discomfort during the treatment. As the area becomes desensitized, the initial discomfort typically fades as it is being treated.

How is the Shockwave treatment performed?
The treatment is noninvasive. First, a gel is applied to the treatment area. Second, an applicator is applied and manipulated to release pressure waves over the affected area. Treatment sessions typically last 5 minutes, but this can vary depending on the area(s) and condition being treated.

What type of results are expected?
Beneficial effects are often experienced after only one or two treatments, and many patients report immediate relief. The technology has a 91% success rate as per clinical studies.

What are the possible side effects?
Treatment with Shockwave technology has virtually no side effects. In some cases, patients may experience minor discomfort for a few days. Patients can return to work after treatments and in most all cases there is no downtime.

Who is a candidate for Shockwave therapy?
Most people are excellent candidates for Shockwave treatment however patients who are pregnant, have a pacemaker or current cancer are not suitable for treatment with Shockwave Technology.
