Back Pain Physical ESWT Shockwave Therapy Machine Physiotherapy
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | SmartWave |
| Certification: | CE |
| Model Number: | BS-SWT5000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiated |
| Packaging Details: | Standard export packing |
| Delivery Time: | Within 3 working days after we received payment of Acoustic Wave Therapy Machine |
| Payment Terms: | T/T, Western Union, MoneyGram, Cash, Alipay |
| Supply Ability: | 500 per month |
|
Detail Information |
|||
| Type: | BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machine | Source: | Precise Compressed Air |
|---|---|---|---|
| Energy: | 1.0 – 5.0 Bar | Energy Setting: | Stepping At 0.1 Bar |
| Burst Mode: | Yes | Frequency: | 1 – 22Hz |
| Counter: | Up/Down | Transmitter: | 6mm/ 15F Mm/ 15C Mm/ 15D Mm/ 25mm / 36mm |
| Hand Piece Lifecycle: | 3 Million Shots | Software: | 8 Pre-set Treatment Guides |
| Software Update: | USB Interface | Customized Setting: | Unlimited |
| Client Profile: | No | ||
| High Light: | Back Pain ESWT Shockwave Therapy Machine,Physical ESWT Shockwave Therapy Machine,Physiotherapy shockwave therapy equipment |
||
Product Description
BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machine
What can BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machinedo in musculoskeletal disorders?
Sources of shock wave generation include electro-hydraulic, electromagnetic and piezoelectric principles. Electro-hydraulic shock waves are high-energy sound waves generated by high-pressure electrode water explosion.
Shock waves in urology (healing) are mainly used to disintegrate urolithiasis, while shock waves in orthotripsy are not used to break down tissue, but to induce tissue repair and regeneration.
Extracorporeal shock wave therapy (ESWT) has been used in musculoskeletal diseases for more than a decade, mainly for the treatment of exercise-related overuse tendinopathy, such as proximal heel fasciitis, lateral elbow gingivitis, calcification Or calcified tendinitis such as non-periarthritis and rickets.
The success rate is between 65% and 91%, with low complications and negligible.
ESWT is also used to treat long bone fractures, avascular necrosis of the femoral head, chronic and non-diabetic ulcers, and non-healing of ischemic heart disease. The vast majority of published papers show positive and beneficial effects.
The FDA (USA) first approved ESWT for the treatment of proximal plantar fasciitis and external epicondylitis in 2002. ESWT is a new non-invasive treatment with no risk of surgery or surgery, clinical ESWT Applications have steadily increased over the years.
SmartWave BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machine, which is a method for the treatment of superficial orthopedic disorders developed over the past 20 years.
BS-SWT5000 SMARTWAVE Shockwave therapy is a new non-invasive solution for musculoskeletal pain. The extracorporeal shockwave therapy is frequently used in physiotherapy, orthopaedics and sports medicine. Applications are mostly associated with treatment of chronic muscular and tendon disorders, back and cervical pain. Most common indications include: painful shoulder, epicondylitis, low back pain, Achilles tendon pain, patellar tendonitis and trigger points. The extreme method of using bundled sound waves with high intensity was selected because the mechanical/acoustic waves of force can be focused at a defined point with a parabolic reflector to ensure that stress limits are not exceeded in the remaining tissue. The penetrating depth can reach 0 - 60mm.
Product Specification
| Model | BS-SWT5000 |
| Shockwave Type | ESWT(extracorporal shockwavetherapy) |
| Therapeutic penetration depth | 30-55mm |
| Effects | Skin/Muscle |
| Energy | 1Bar to 5Bar ,stepping 0.1Bar |
| Frequency | 1-22Hz |
| Pulse Mode | Continuous or Burst |
| Transmitter | 5 for different applications |
| Encyclopedia | Live help with pre-set parameters |
| Treatment Protocols | 8 preset protocols |
| Customer Profile Management | NO |
| User Defined Setting | NO |
| Multi-Language | Yes |
| Conformity |
EN60601-1-2,EN61000-3-2/3,EN60601-1:2006 |
From the view of transmitter, BS-SWT5000 smartwave has 6 different alloy made transmitters targeting to different depth and treatment disease.It includes 6mm/ 15F mm/ 15C mm/ 15D mm/ 25mm / 36mm for optional, more for ODM) which covers most applications for physical treatments as well as aesthetics treatments.
Energy levels from 1.0 Bar to 5.0 Bar, adjustable, stepping at 0.1Bar Frequency up to 22Hz, adjustable from 1Hz to 22Hz,stepping at 1Hz.
Applications for Epicondylitis, Tendonitis, Biceps Tendonitis, Achilles Tendonitis, Lower Back Pain of muscular origin, Trigger Points, Plantar Fascitis, and aesthetic applications as Cellulite therapy, Stretchmark elimination, Skin tightening and body reshaping. It is widely installed for treatment target which covers: rehabilitation medicine, orthopedics, sport medicine, medical cosmetology, pain treatment (chronic/acute), dermatology, geriatrics, acupuncture (include Chinese traditional medic.
Features of BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machine
- Pressure from 1.0 Bar to 5.0 Bar Adjustable
- Frequency from 1Hz to 22Hz Adjustable
- Rich pre-set treatment protocols
- Precise energy adjusting stepping at 0.1Bar
- As many as 6 transmitters and more for OEM
- Long lifecycle design and easy to maintain
- Deep penetration and good treatment result
Conditions treatable with BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machine:
Some common uses of the Shockwave Smartwave are:
· Shoulder: Calcification of the Shoulder, Frozen Shoulder, Restricted movement
· Chronic Elbow Pain: Tennis Elbow / Golfers Elbow
· Chronic Tendonitis of the Shoulder / Elbow / Wrist / Hip / Knee / Ankle
· Achilles Tendinosis / Plantar Fasciitis and Heel Spurs
· Chronic neck, shoulder or back pain and tension (trigger points)
· Proximal iliotibial band friction syndrome
Shockwave for Cellulite Reduction:
· Temporary reduction in the appearance of cellulite
· Deep tissue massage
· Lymphatic drainage
· Body shaping & Skin elasticity improvement
FOR BS-SWT5000 Back Pain Physical Therapy Physiotherapy Shockwave Machine
Just Contact Ray Liu
